SCIENCEWAY 600 D VACCUME MACHINE
The DZ 600 series (also referred to as "600 D") represents a line of heavy-duty, stainless-steel vacuum packaging machines designed for medium to high-volume industrial use.
Product Overview
The DZ‑600 series (also referred to as "600 D") represents a line of heavy-duty,
stainless-steel vacuum packaging machines
designed for medium to high-volume industrial use. Available in single-chamber or double-chamber
configurations, these models support high throughput and maximum packaging
efficiency.
Double-chamber systems enable users to load one chamber
while the other finishes the vacuum-seal-cool cycle—ideal for uninterrupted
operations. This feature is essential in high-output environments such as food
processing plants, pharmaceutical packaging lines, electronic component
encapsulation, or large-scale laboratory operations.
Constructed from DIN‑standard stainless
steel (SUS304), the machine ensures superior
hygiene and corrosion resistance. Depending on the variant, chamber lids may
feature automated or manual actuation, enhanced transparency for cycle monitoring, and optional gas-flush
or soft-air systems for handling fragile
products.
Specifications
| Model | DZ 600 (single chamber or double chamber versions) |
| Voltage | AC 220 V/50 Hz or AC 380 V/50 Hz (3-phase variants available) |
| Motor Power | Around 1.5 kW (depending on variant) |
| Sealing Heater Power | ~1.0 kW per chamber, sometimes dual seal bars |
| Ultimate Vacuum Pressure | Achieves ~1.0 kPa (≤ 1 kPa) |
| Vacuum Pump Capacity | 40 m³/h per machine unit |
| Sealing Length | 600 mm (sometimes using 2–4 seal bars) |
| Seal Width | 8–10 mm |
| Chamber Dimensions | ~660 × 540 × 45 mm (single) or ~700×680×45 mm (double) |
| Overall Machine Size | Approx. 1460 × 590 × 980 mm (double chamber) |
| Net Weight | ~320–350 kg (double chamber), ~110 kg (single chamber variant) |
| Cycle Productivity | Typically 2–4 cycles/min (single chamber); up to 3–5/min with double units |
| Material | Industrial-grade stainless steel (SUS 304) |
| Operation Mode | Semi-automatic or fully automatic with PLC control or digital timer options |
| Optional Features | Gas flush, soft air, wheel-mounted frame, multi-bar sealing variants |
