SCIENCEWAY AUTOMATIC INDUCTION SEALING MACHINE 20 TO 100 MM
The Scienceway Automatic Induction Sealing Machine is a high-performance packaging solution designed to seal containers with aluminum foil caps using electromagnetic induction.
Product Overview
The Scienceway Automatic
Induction Sealing Machine is a high-performance packaging
solution designed to seal containers with aluminum foil caps using
electromagnetic induction. It efficiently seals bottles with cap diameters
ranging from 20 mm to 100 mm, ensuring a
tamper-proof, leak-proof, and contamination-free seal. The machine operates
automatically, making it ideal for continuous production environments across
industries such as food, pharmaceuticals, cosmetics, and chemicals. With a
compact and durable design, it provides consistent sealing quality without
direct contact with the product, enhancing shelf life and product integrity.
Specifications
| Sealing Cap Diameter | Ø 20 mm to Ø 100 mm |
| Model Examples | e.g. DCGY F200 / GLF 500F / GLF 500A |
| Input Voltage | AC 220 V / 50 Hz (also supports 110 V / 60 Hz in some versions) |
| Power Consumption | Typically 500 W; some models support adjustable 800–1200 W for speed/quality optimization |
| Sealing Speed (Capacity) | Approximately 5–20 bottles/min (depending on model and operation mode) |
| Control System | Microcomputer/digital panel with adjustable sealing time, auto counting, over current/voltage protection |
| Dimensions (L × W × H) | Around 340 × 290 × 150 mm |
| Net Weight | Lightweight portable design: ~3 kg for tabletop units |
| Cooling System | Air-cooled induction head for continuous operation |
| Ambient Operating Conditions | Temperature up to ~45 °C; humidity ≤ 80% RH |
| Construction Material | Compact stainless steel or powder-coated body; induction coil with safety shielding |
