SCIENCEWAY INDUCTION SEALING MACHINE DCGYF500C

The Scienceway DGYF 500C induction sealer is a powerful, yet compact handheld unit that delivers fast, tamper evident, and leak proof foil seals on capped bottles and containers.

Product Overview

The Scienceway DGYF‑500C induction sealer is a powerful, yet compact handheld unit that delivers fast, tamper‑evident, and leak‑proof foil seals on capped bottles and containers. Using non-contact electromagnetic induction, it generates instant heat to melt the aluminum foil liner inside the cap, creating a clean and hermetic seal without affecting the bottle or its contents

Specifically engineered for industrial environments such as pharmaceuticals, cosmetics, food & beverages, chemicals, and lubricants, this sealer supports bottle cap diameters ranging from approximately 60–130 mm, making it versatile for a wide variety of container types.

Designed for batch sealing applications, the DGYF‑500C excels in scenarios where portability, rapid seal time, and consistent performance are essential. It features adjustable sealing duration and built-in safety protections, including overheat and overload protection, ensuring reliable sealing quality and operator safety.

Its compact, lightweight form allows easy handheld or inline use, enabling flexible deployment across production lines or mobile sealing tasks. Advanced sealing technology minimizes product spoilage and provides a premium seal appearance—ideal where extended shelf-life and brand integrity matter.

Specifications
Model DGYF 500C
Power Supply AC 220 V ± 10% / 50–60 Hz (110 V option available)
Power Consumption / Output ~500–600 W (~0.5–1 kW power)
Operating Frequency ~50 kHz (induction operating frequency)
Cap Sealing Diameter Range 60 mm – 130 mm (suitable for large bottle caps, including drum and jar lids)
Sealing Time 2–3 seconds per cap; adjustable via timer panel
Sealing Speed / Output Approximately 10–30 caps/min (adjustable, operator dependent)
Machine Dimensions ~340 × 290 × 150 mm
Machine Weight Approx. 5 kg
Construction Material Portable lightweight ABS housing, ergonomic design
Safety & Controls Digital timer display, overheat and overcurrent protection, auto shutoff and cooling system
Foil Compatibility Special induction film or aluminum-foil laminate liners
Certifications CE, ISO certified (likely ISO 9001)
Warranty Typically includes 6 month standard manufacturer warranty
