SCIENCEWAY INDUCTION SEALING MACHINE DCGYF600C
The Scienceway DGYF 600C is a portable, handheld induction sealer designed for creating clean, tamper-evident, and leak-proof foil seals on capped containers like bottles, jars, and drums.
Product Overview
The Scienceway DGYF‑600C
is a portable, handheld induction sealer designed for creating clean,
tamper-evident, and leak-proof foil seals on capped containers like
bottles, jars, and drums. Employing non-contact electromagnetic induction,
it instantly melts aluminum-foil liners inside caps to produce a hermetic
seal—without heat affecting the container or its contents
Built for
demanding industrial environments—such as pharmaceuticals,
food & beverage, cosmetics, chemicals, and oils—it is especially
well-suited to sealing larger caps up to approximately 100–130 mm in diameter
With a lightweight,
ergonomic design, the DGYF‑600C offers flexible use for inline production
or mobile batch sealing. Its adjustable sealing settings and built-in
safety controls ensure consistent, repeatable seal quality—even in varied
production conditions
Specifications
| Model | DGYF 600C (portable handheld induction sealer) |
| Cap Sealing Diameter Range | 60 mm – 130 mm (some sources list 20–120 mm or 20–100 mm variants) |
| Power Supply | AC 220 V ±10% / 50–60 Hz (110 V option available) |
| Power Consumption | Approx. 500 W – 600 W |
| Sealing Cycle / Speed | Adjustable sealing time; up to ~30 caps/min depending on cap size & operator |
| Dimensions (L × W × H) | ~340 × 290 × 150 mm |
| Machine Weight | ~3.5 kg – 5 kg (portable, lightweight) |
| Cooling System | Air-cooled design via built-in fan |
| Control & Safety | Digital timer display; overheat and overcurrent protection; auto shut-off on overload |
| Compatible Materials | PET, PP, HDPE, LDPE, PS, PVC, glass containers with aluminum foil liners |
| Construction Material | ABS or industrial-grade plastic housing; ergonomic handheld design |
| Certifications | CE certified |
