SCIENCEWAY TIJ PRINTER 4 HEAD 12.7MM
The SCIENCEWAY 4 Head TIJ Printer 12.7 mm is a high-performance industrial inkjet solution designed for wide-format and multi-line printing needs.
Product Overview
The SCIENCEWAY 4 Head TIJ Printer
12.7 mm is a high-performance industrial inkjet solution
designed for wide-format and multi-line printing needs. Equipped with four
independent 12.7 mm TIJ 2.5 heads, it delivers a combined print height of up to
50.8 mm, allowing for large logos, stacked barcodes, multilingual text, and
variable data to be printed simultaneously. Ideal for high-speed production
lines, it ensures sharp, high-resolution output on diverse materials such as
cartons, plastics, metals, and pipes. The system supports easy integration, user-friendly
touchscreen control, and maintenance-free operation using HP-compatible ink
cartridges for reliable, continuous marking.
Specifications
| Print Technology | Thermal Inkjet (TIJ 2.5 – 4 Independent Heads) |
| Total Print Height | Up to 50.8 mm (4 × 12.7 mm) |
| Print Resolution | 40 to 600 dpi (adjustable) |
| Printing Speed | Up to 120 meters per minute |
| Supported Content | Text, logos, barcodes, QR codes, batch/date/time |
| Display | 7″ or 10″ color touchscreen |
| Ink Compatibility | Solvent-based, water-based, UV inks |
| Ink Colors | Black, white, red, blue, yellow, green |
| Interfaces | USB, Encoder, Photoelectric sensor |
| Language Support | English, Arabic, French, Spanish, and more |
| Memory Capacity | 1000+ messages (internal + USB) |
| Build Material | Industrial aluminum alloy |
| Throw Distance | 2–5 mm |
| Operating Temperature | 0°C to 45°C |
| Humidity Range | 30% to 80% RH (non-condensing) |
| Power Supply | AC 100–240V / 50–60 Hz |
| Head Dimensions | ~200 × 135 × 128 mm per unit |
