The Scienceway DGYF 500C induction sealer is a powerful, yet compact handheld unit that delivers fast, tamper evident, and leak proof foil seals on capped bottles and containers.
The Scienceway
DGYF‑500C induction sealer is a powerful, yet compact handheld unit that
delivers fast, tamper‑evident, and leak‑proof foil seals on capped
bottles and containers. Using non-contact electromagnetic induction, it
generates instant heat to melt the aluminum foil liner inside the cap, creating
a clean and hermetic seal without affecting the bottle or its contents
Specifically
engineered for industrial environments such as pharmaceuticals,
cosmetics, food & beverages, chemicals, and lubricants, this sealer
supports bottle cap diameters ranging from approximately 60–130 mm,
making it versatile for a wide variety of container types.
Designed
for batch sealing applications, the DGYF‑500C excels in scenarios where portability,
rapid seal time, and consistent performance are essential. It
features adjustable sealing duration and built-in safety protections,
including overheat and overload protection, ensuring reliable sealing quality
and operator safety.
Its compact,
lightweight form allows easy handheld or inline use, enabling flexible
deployment across production lines or mobile sealing tasks. Advanced sealing
technology minimizes product spoilage and provides a premium seal
appearance—ideal where extended shelf-life and brand integrity matter.
Model | DGYF 500C |
Power Supply | AC 220 V ± 10% / 50–60 Hz (110 V option available) |
Power Consumption / Output | ~500–600 W (~0.5–1 kW power) |
Operating Frequency | ~50 kHz (induction operating frequency) |
Cap Sealing Diameter Range | 60 mm – 130 mm (suitable for large bottle caps, including drum and jar lids) |
Sealing Time | 2–3 seconds per cap; adjustable via timer panel |
Sealing Speed / Output | Approximately 10–30 caps/min (adjustable, operator dependent) |
Machine Dimensions | ~340 × 290 × 150 mm |
Machine Weight | Approx. 5 kg |
Construction Material | Portable lightweight ABS housing, ergonomic design |
Safety & Controls | Digital timer display, overheat and overcurrent protection, auto shutoff and cooling system |
Foil Compatibility | Special induction film or aluminum-foil laminate liners |
Certifications | CE, ISO certified (likely ISO 9001) |
Warranty | Typically includes 6 month standard manufacturer warranty |
