SCIENCEWAY TIJ PRINTER 4 HEAD 25MM
The SCIENCEWAY 4 Head TIJ Printer 25 mm is an industrial-grade high-resolution printing system designed for wide-area marking applications. It combines four 25 mm thermal inkjet heads to deliver seamless printing across a total height of up to 100 mm. Ideal for large logos, wide barcodes, batch codes, and multi-line text, it ensures crisp, high-speed printing on cartons, wood, plastic, metal, and more
Product Overview
The SCIENCEWAY 4 Head TIJ Printer 25 mm is an
industrial-grade high-resolution printing system designed for wide-area marking
applications. It combines four 25 mm thermal inkjet heads to deliver seamless
printing across a total height of up to 100 mm. Ideal for large logos, wide
barcodes, batch codes, and multi-line text, it ensures crisp, high-speed
printing on cartons, wood, plastic, metal, and more. Engineered for continuous
operation in demanding environments, this printer offers fast-drying ink
compatibility, multilingual touchscreen control, and maintenance-free
performance using HP TIJ 2.5 cartridge technology.
Specifications
| Print Technology | Thermal Inkjet (TIJ 2.5 – 4 Heads) |
| Individual Head Height | 25.4 mm per head |
| Total Print Height | Up to 101.6 mm (4 × 25.4 mm) |
| Print Resolution | 40 to 600 dpi (adjustable) |
| Printing Speed | Up to 120 meters per minute |
| Print Content | Text, logos, barcodes (1D/2D), QR codes, dates |
| Display | 7″ or 10″ color touchscreen |
| Ink Compatibility | Solvent-based, water-based, UV-curable inks |
| Ink Colors | Black, white, red, blue, yellow, green |
| Interfaces | USB, Encoder, Photoelectric sensor |
| Language Support | Multilingual (English, Arabic, French, etc.) |
| Storage Capacity | 1000+ messages (internal + USB backup) |
| Housing Material | Industrial-grade aluminum alloy |
| Throw Distance | 2–5 mm (optimal) |
| Operating Temperature | 0°C to 45°C |
| Humidity Range | 30% to 80% RH (non-condensing) |
| Power Supply | AC 100–240V / 50–60 Hz |
| Head Dimensions | Approx. 200 × 135 × 128 mm per head |
