FLY BOTTLE MAKING MACHINE
| No. | Functionality | Description |
|---|---|---|
| 1 | Commodity name | Fly Bottle Marking Machine |
| 2 | Laser Power | 30W |
| 3 | Laser Type | RF excited CO2 laser |
| 4 | Laser lifespan | 45?000hrs |
| 5 | Marking speed | 0-7000 mm/s |
| 6 | Optical quality | ?1.2 m2 ( sqm) |
| 7 | Marking range | 110mm*110mm(175mm*175mm is optional) |
| 8 | Min.Line | 0.12mm |
| 9 | Laser wavelength / beam | 10.6µm |
| 10 | Min. shaping character | 0.4 mm |
| 11 | Resetting pos.accuracy | ± 0.01 mm |
| 12 | Transmission | Vibration galvanometer |
| 13 | Graphic format supported | BMP,JPG,DXF,PLT,AI etc. |
| 14 | Power supply | Ac 220 v ± 10% , 50 Hz |
| 15 | Cooling method | Air cooling |
| 16 | Gross power | < 1.2kw |
| 17 | Net weight | 95 kg |
| 18 | Dimension | L1450mm*W800mm*H1730mm |
| 19 | Supported Bar code | UPC,EAN,CODE39,etc. |
| 20 | Optional device | Rotary attachment, fume filter |
